220-ton Capacity PLC Controlled IP68 Waterproof Road Blocker System for High-Security Vehicle Access Control

Large Image : 220-ton Capacity PLC Controlled IP68 Waterproof Road Blocker System for High-Security Vehicle Access Control

Product Details:

Place of Origin:	China
Brand Name:	Sikerui
Certification:	CE / RoHS / FCC
Model Number:	SST5000-5M

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	$5000-10000
Packaging Details:	Wooden Box
Delivery Time:	5-7days
Payment Terms:	T/T,L/C
Supply Ability:	5000 Units Per Month

Contact Now Chat Now

220-ton Capacity PLC Controlled IP68 Waterproof Road Blocker System for High-Security Vehicle Access Control

Description

Control System:	PLC Controls Programming Commands	Rated Voltage:	AC380V 50Hz
System Power:	3.75KW	Working Temperature:	-30℃ To 75℃
Lifting Height:	500mm Or 600mm	Protection Grade:	IP68

Road Blocker System for Perimeter Security and Vehicle Access Control

SST5000-4M Road Blocker

High-security vehicle access control solution designed for critical infrastructure protection. The SST5000 Road Blocker provides a robust barrier against unauthorized vehicle access, engineered for high-traffic environments and maximum security performance.

Key Benefits

Superior Security: Prevents unauthorized vehicle entry
Heavy-Duty Construction: Withstands heavy container trucks up to 220 tons
PLC Controlled: Programmable logic control for customized operation
Manual Override: Can be raised and lowered manually during power failure
Wide Temperature Range: Operates in extreme temperatures from -30℃ to 75℃ (with optional low-temperature device)

Target Applications: Government facilities, military bases, airports, seaports, industrial complexes, toll booths, parking facilities, and any location requiring high-security vehicle access control.

Technical Specifications

Parameter	Description
Control System	PLC controls programming commands
Control Mode	Wireless remote control and wire control
Minimum Passing Pressure	Container trucks under 220 tons can pass
Rated Voltage	AC380V 50Hz
System Power	3.75KW
Power Unit	Electro-hydraulic drive
PLC Built-in Encryption System	It can be encrypted
Rising Time	≤1-4S
Descending Time	≤1-4S
Working Temperature	(-30℃~75℃) (low temperature device installed -50~75℃)
Material	Q235
Lifting Height	500mm and 600mm are optional
Standard Thickness of Panel	16mm, 20mm and 25mm are optional
Spine Length	350mm
Box Size	(2000-6000)1000760mm
LED Warning Light	Monochrome and multicolor are optional
Reflective Film	3M diamond grade
Linkage Interface	Traffic lights, infrared, ground sense, license plate recognition, etc
In case of power failure	It can be raised and lowered manually
Protection Grade	IP68
Remote Control Range	50-100M
Noise during device operation	≤ 60dB
